      6ED1055-1HB00-0BA2 LOGO! DM8 24R EXPANSION MODULE,
      Artikelnummer6ED1055-1HB00-0BA2
      LOGO! DM8 24R EXPANSION MODULE, PU/I/O: 24V/24V/RELAY, 2TE 4 DI/4 DO, AC/DC/NPN INPUT FOR LOGO! 8
      Installation type/mounting
      Mountingon 35 mm DIN rail, 2 spacing units wide
      Supply voltage
      24 V DCYes
      permissible range, lower limit (DC)20.4 V
      permissible range, upper limit (DC)28.8 V
      24 V ACYes
      Line frequency
      ● permissible frequency range, upper limit63 Hz
      Digital inputs
      Number of digital inputs4
      Input voltage
      ● Type of input voltageAC/DC
      Input current
      ● for signal "0", max. (permissible quiescent current)1.1 mA
      ● for signal "1", typ.5.5 mA
      Input delay (for rated value of input voltage)
      for standard inputs
      — at "0" to "1", max.1.5 ms
      — at "1" to "0", max.15 ms
      Digital outputs
      Number of digital outputs4; Relays
      short-circuit protectionNo
      Controlling a digital inputYes
      Switching capacity of the outputs
      ● Lamp load, max.1 000 W
      Output current
      ● for signal "1" rated value5 A
      Parallel switching of 2 outputs
      ● for increased powerNo
      Switching frequency
      ● with resistive load, max.2 Hz
      ● with inductive load, max.0.5 Hz
      ● mechanical, max.10 Hz
      Relay outputs
      Switching capacity of contacts
      — with inductive load, max.3 A
      — with resistive load, max.5 A
      EMC
      Emission of radio interference acc. to EN 55 011
      ● Limit class B, for use in residential areasYes
      Degree and class of protection
      Degree of protection to EN 60529
      ● IP20Yes
      Standards, approvals, certificates
      CSA approvalYes
      UL approvalYes
      FM approvalYes
      Developed in accordance with IEC 61131Yes
      according to VDE 0631Yes
      Marine approval
      ● Marine approvalYes
      Ambient conditions
      Operating temperature
      ● Min.0 °C
      ● max.55 °C
      Dimensions
      Width35.5 mm
      Height90 mm
      Depth58 mm
      last modified:14.10.2014
